1 1000M RJ45 Ethernet Port 3 100M Ports ONU Fiber Device Industrial

Name: 1 1000M RJ45 Ethernet Port 3 100M Ports ONU Fiber Device Industrial
Brand: Hioso
Price: 1 USD

China 1 1000M RJ45 Ethernet Port 3 100M Ports ONU Fiber Device Industrial wholesale

Brand Name : Hioso

Model Number : HA7404GH

Certification : CE, RoHS, CCC

Place of Origin : China, Guang dong

MOQ : 1

Price : Negotiable

Payment Terms : T/T

Supply Ability : 5000pcs / month

Delivery Time : 4-9 working days

Packaging Details : 34*30*12cm

Item : 4 port gpon onu

Power : DC 48V

Cache space : 1.25MB

MTBF : 100,000 hours

Optical power : 0~+4dBm

Standard : ITU-T G984

Contact Now

Gpon Onu 1 1000M RJ45 Ethernet Port + 3 100M Ports Industrial 4port Onu

Overview

HA7404GH GPON/XPON ONT is designed for fulfilling FTTH ultra-broadband access request of home and SOHO users. HA7404GH supplies one 10/100/1000M RJ45 Ethernet port, three 10/100M Ethernet ports. It is based on the stable and mature GPON/XPON technology, which has high performance/price ratio, and the technology of layer 2 as well.It supports both GPON and EPON OLT. It is highly reliable and easy to

maintain, with guaranteed QoS, and fully compliant to ITU-T G.984 GPON standards.

Technical Specification

Parameter	Specification
Main chip	ZTE
Uplink PON interface	1 GPON interface, SC single-mode/single-fibre, uplink 1 .25Gbps, downlink 2.5Gbps
Downlink LAN interface	1* 10/100/1000Mbps 3* 10/100Mbps Full Duplex/Half Duplex, RJ45 connector
Wavelength	Tx 1310nm, Rx 1490nm
Optical power	0~+4dBm
Receiving sensitivity	-27dBm
Max transmission distance	20 km
Cache space	1.25MB
MTBF	100,000 hours
GPON trait	ITU-T G984 Standard Supports 32 TCONT,256 gemports Support the 984 standard AES128 encryption function Support SBA and DBA

Working Envrioment

Parameter	Specification
Power	DC12V/1A (outside power)
Power consumption	3.7W
Operating temperature	-10—55 ℃ wide temperature range-T:-40~75℃
Storage temperature	-40—85 ℃
Humidity	5%～90% non-condensing
Dimension	26mm140mm106mm
Net weight	0.5Kg
